DJI Osmo Mobile 7 Pro

Dimensions
Osmo Mobile 7P
Unfolded: 288×107×96 mm (L×W×H)
Folded: 190×95×46 mm (L×W×H)

Osmo Mobile 7
Unfolded: 278×107×93 mm (L×W×H)
Folded: 179×95×39 mm (L×W×H)
Weight
Osmo Mobile 7P
Gimbal + Built-in Tripod + Magnetic Phone Clamp + Multifunctional Module: Approx. 368 g

Osmo Mobile 7
Gimbal + Built-in Tripod + Magnetic Phone Clamp: Approx. 300 g

Data was collected in a controlled environment. Actual experience may vary.
Extension Rod
Osmo Mobile 7P
Built-in Extension Rod
Max Extension Length: 215 mm

Osmo Mobile 7
No Built-in Extension Rod
Compatible Phone Weight 170-300 g
Compatible Phone Thickness 6.9-10 mm
Compatible Phone Width 67-84 mm
Bottom Port 1/4" Screw Hole

Battery
Type Li-Po 1S
Capacity 3350 mAh
Energy 12.06 Wh
Charging Temperature 5° to 40° C (41° to 104° F)
Operating Temperature 0° to 40° C (32° to 104° F)
Operating Time Osmo Mobile 7P
Approx. 10 hours (Measured with the gimbal balanced in a level and stationary state without additional accessories)

Osmo Mobile 7
Approx. 10 hours
(Measured with the gimbal balanced in a level and stationary state without additional accessories)

With the Multifunctional Module's intelligent tracking feature enabled and the fill light off, the operating time is approximately 5 hours. When the intelligent tracking feature is on and the fill light is set to maximum brightness, the operating time is approximately 4 hours.Using the gimbal to charge your smartphone will shorten the gimbal's operating time.
Charging Time Approx. 2.5 hours
(Measured with a 10W USB-C charger)
Gimbal Charging Port
USB-C
Phone Charging
Supported

Gimbal
Controllable Range Pan: -99° to 210°
Roll: -67° to 245° Tilt: -20° to 40°
Mechanical Range Pan: -109° to 222°
Roll: -77° to 255° Tilt: -224° to 100°
Max Control Speed 120°/s
Wireless Mode Model
Bluetooth 5.3

Software App DJI Mimo

Tripod
Dimensions
Built-in Tripod
Length: 67 mm

Multifunctional Module
Compatibility
Osmo Mobile 7P
Supported (standard)

Osmo Mobile 7
Supported (optional)

GFSK
2 Mbps
GFSK Transmitter Power (EIRP)
< 16 dBm

GFSK Operating Frequency
2.4000-2.4835 GHz

Bluetooth Protocol
Bluetooth 5.3

Bluetooth Transmitter Power (EIRP)
< 16 dBm

Bluetooth Operating Frequency
2.4000-2.4835 GHz

Fill Light Illuminance
40 lux

This represents the maximum brightness measured at a distance of 0.6 meters from the subject and should be used for reference only.
Fill Light Color Temperature
2500-6000 K
